Description
A manual rolling security shutter for a standard 48″ × 48″ window opening, operated by a smooth spring-assist mechanism with a built-in key lock — no power or wiring required. The insulated aluminum slats deliver serious security, sun and heat protection, and quieter rooms, making it one of the most popular security shutters for windows. Made in the USA and ready to ship in about 7 days.
Don’t have a 48″ × 48″ opening? Custom sizes are available — request a free quote and we’ll build it to fit.
Our team is standing by to answer your questions, give you a quote, and find the best solution for your project.
☎ Call (480) 921-0200 or request a free quote.
Available colors (same price)
Slat options
- 38mm Insulated (this model) — Slim 38 mm insulated slat — security plus noise & thermal insulation
- 55mm Insulated — Larger 55 mm insulated slat for bigger openings (up to 18 ft wide)
- 63mm Single Wall — Extruded aluminum, maximum strength — hurricane-rated up to 20 ft
- 63mm Single Wall (Perforated) — Vented single-wall slat — lets in light and air while staying secure
Operator options
- Strap (Pull or Crank) — Manual — pull strap or hand crank
- Spring Assisted (this model) — Spring-assist lift with a key lock
- Gear/Wand — Manual geared wand for larger shutters
- Hardwired Motor — Wired to a wall switch for one-touch operation
- Remote Motor — Operated by a handheld remote
- Solar-Powered Motor — Solar-charged motor — no wiring needed
- Battery-Powered Motor — Rechargeable battery motor — no wiring needed
Specifications
| Slat type | 38mm Insulated |
| Composition | Rolled aluminum with an insulating foam core |
| Slat height | 1.5 in (38 mm) |
| Slat thickness | 0.4 in |
| Insulation | Noise + thermal (R-value) insulated |
| Operation | Manual spring (spring-assist) |
| Color | White |
| Clear opening (this model) | 48″ × 48″ |
| Overall unit size | 52⅛” W × 56⅝” H |
| Max custom size (this slat) | 12 ft W × 12.5 ft H |
| Mounting | Surface |
| Curtain weight | 16.77 lbs |
| Lead time | ~7 days |
| Country of origin | USA — Tempe, Arizona |
| Warranty | 5-year shutter parts · 5-year motors · 2-year electronic components · 1-year labor |
| Hurricane rating | This configuration is not hurricane-rated. For hurricane-rated protection, choose our 63mm Single Wall slat (available by custom quote). Request a free quote |
What’s included
- 38mm Insulated curtain (36 solid slats), white
- Surface-mount box (6.5″) + H-Mini guide rails + end slat
- Manual spring (spring-assist) operator
- U-Channel + installation guide & video access
How it works
Spring-assist operator with a key lock on the box side — lift to open, pull down to close and lock.
Common questions
How is the manual spring operated?
A spring-assist mechanism counterbalances the curtain so it raises and lowers easily by hand, then locks with the key lock on the box side. No electricity needed.
Is this a standard size or custom?
This is a standard, pre-built security shutter for a 48″ × 48″ clear opening, built and shipped fast (about 7 days), exactly as shown. Need a different size or configuration? Request a free custom quote and we’ll build it to fit your exact opening.
How do I know it will fit?
You need a 48″ × 48″ clear opening, plus surface space for the overall unit (roughly 52″ × 57″ for the 38mm models). Not sure? Call us at (480) 921-0200 — our team is standing by to size it for you — or request a free quote.
Can I install it myself?
Yes. Every shutter ships with an installation guide and video. In metro Phoenix we also install locally — request a quote for installed pricing. Questions about installation? Call (480) 921-0200 and we’ll walk you through it.
What’s your warranty?
5 years on shutter parts and motors, 2 years on electronic components, and 1 year on labor — the same coverage for residential and commercial.
Shipping and returns?
Freight is calculated at checkout. Because each shutter is made to order, sales are final except for defects or freight damage reported within 3 business days.
Our team is standing by to answer your questions, give you a quote, and find the best solution for your project.
☎ Call (480) 921-0200 Request a free quote
